Home Application 1900mAh 2550mAh 1700mAh Lipo Rechargeable Battery 3.7 V 10C 15C Usb External Dog Toy Ball 782768SV2 1003055SV2
1900mAh 2550mAh 1700mAh Lipo Rechargeable Battery 3.7 V 10C 15C Usb External Dog Toy Ball 782768SV2 1003055SV2

1900mAh 2550mAh 1700mAh Lipo Rechargeable Battery 3.7 V 10C 15C Usb External Dog Toy Ball 782768SV2 1003055SV2

50Kpcs For Stacking Cell Per Day, 200Kpcs For Winding Cells Per Day
1003055SV2-1900
Chat Now
Service Hotline:
0752-2322511
High Rate Discharge Li-Po Battery

Fullymax focuses on the high rate discharge pouch batteries, including power batteries for electric aviation aircraft (eVTOL), electric power , drones, electronic cigarettes, fast charging batteries,12V/48V Start/Stop batteries and jump starter for car, RC professional remote control models and toy , military and special equipment, etc. FULLYMAX batteries are also widely used in smart home like sweeping robots, vacuum cleaners, small power tools, etc.; 3C consumer electronics like remote control handles, beauty equipment, portable projectors, etc., smart Bluetooth products, medical equipment ,ect

Industry-leading high temperature & high power discharging capability
Outstanding gravimetric Energy density: max 280Wh/kg
Low IR, low temperature rising, low self-discharging
Longer cycle life:1C ≥1000 cycles , 100% DOD
Good consistency, stable performance
LCO(4.2V/4.35V/4.4V/4.45V),LFP and NCM ,Flexible customized solution
Product Details
Place of Origin:
China
Brand Name:
FULLYMAX
Model Number:
1003055SV2-1900
User-defined Attribute
Supply Ability:
50Kpcs For Stacking Cell Per Day, 200Kpcs For Winding Cells Per Day
Model No.:
1003055SV2-1900
Capacity:
1950mAh
Voltage:
3.85V
Max Cont. Discharge:
10C
Dimensions(H X W X L ):
7.8x27x60mm
Weight:
22g
Cycle Life:
500 Times More
OEM/ODM:
Accepatable
Optional Accessories:
PCB/Wire
Type:
Li-Ion, Lifepo4
Application:
Power Tool, Camcorders, Battery Pack, Electronic Toy Dog Rechargeable Battery, E-bike
Package:
Blister Disc
Battery Type:
Nimh, Low Self Discharge Battery, Battery Pack, Li-polymer Battery, LI-ION Battery
High Light:

rechargeable lipo battery 3.7 v fullymax

,

lipo rechargeable battery 3.7v

,

3.7 v lithium polymer rechargeable battery fullymax



FULLYMAX 782768SV2 1003055SV2 1900mAh 2550mAh 1700mAh 3.7V 10C 15C rechargeable usb external battery pack dog toy



1900mAh 2550mAh 1700mAh Lipo Rechargeable Battery 3.7 V 10C 15C Usb External Dog Toy Ball 782768SV2 1003055SV2 0

1900mAh 2550mAh 1700mAh Lipo Rechargeable Battery 3.7 V 10C 15C Usb External Dog Toy Ball 782768SV2 1003055SV2 1

1900mAh 2550mAh 1700mAh Lipo Rechargeable Battery 3.7 V 10C 15C Usb External Dog Toy Ball 782768SV2 1003055SV2 2





1900mAh 2550mAh 1700mAh Lipo Rechargeable Battery 3.7 V 10C 15C Usb External Dog Toy Ball 782768SV2 1003055SV2 3     Related Feature

1900mAh 2550mAh 1700mAh Lipo Rechargeable Battery 3.7 V 10C 15C Usb External Dog Toy Ball 782768SV2 1003055SV2 4

For other configurations (without discharge plug) with same cell model, please refer below table.



Model No. Voltage Max cont. discharge Dimensions Weight Application
FBC782768SV2-1750 3.85V 10C 7.8x27x68mm 30.0g Toys
FBC881630XL-330 3.85V 20C 8.8x16x30mm 7.0g Toys
FBC782760SV-1300 3.85V 10C . 10x30x55mm 33.0g Toys
FBC1003055SV2-1900 3.85V 10C 7.8x27x60mm 22.0g Toys
FBC993177SV-2550 3.85V 20C 9.9x31x77mm 51.0g Toys
FBC802760SV-1300 3.85V 15C 8x27x60mm 25.3g Toys
FBC822047SV-730 3.85V 20C 8.2x20x47mm 15.0g Toys
FBC1102760SV-1950 3.85V 10C 11x27x60mm 36.3g Toys
FBC822456XV-1100 3.8V 20C 8.5x24x56mm 23.0g Toys
FBC792540HP-660 3.7V 30C 8.0x26x45mm 22.0g Toys/Mini UAV
FBC903048XL-1000 3.7V 20C 9.8x31x54mm 35.0g Toys
FBC852025XL -300 3.7V 20C 8.5x17x26mm 7.0g Toys
FBC851626XL-250 3.7V .15C. 8.5x17x26mm 6.0g Toys
FBC902540HE-750 3.7V 10C 10x25x40mm 18.0g Toys
FBC903055HE-1500 3.7V 10C 9x30x55mm 30.0g . Toys
FBC702350HP-700 3.7V 25C 7x23x50mm 16.0g Toys
FBC853480HP-2000 3.7V 30C . 8.5x34x80mm 48.0g Toys
FBC701723HP-140 3.7V 30C 7x17x23mm 4.0g Toys
FBC752540XL-550 3.7V 20C 7.5x25x40mm 13.0g Toys
FBC802036XL-420 3.7V 15C 8x20x36mm 10.0g Toys
FBC852025XL-300 3.7V 20C 8x20x25mm 7.0g Toys









1900mAh 2550mAh 1700mAh Lipo Rechargeable Battery 3.7 V 10C 15C Usb External Dog Toy Ball 782768SV2 1003055SV2 5     Product Feature 1900mAh 2550mAh 1700mAh Lipo Rechargeable Battery 3.7 V 10C 15C Usb External Dog Toy Ball 782768SV2 1003055SV2 4

Custom size, lipo battery pack can be made, just tell us your requirement on size, pcb wires connectors,
quantity on samples and big shipment;
we will select a suitable sizeand check the cost for you



- Professional and experienced technical team for independent R&D, flexible and reliable technical service customization.



-  4.2V / 4.35V / 4.4V Multi Voltage System, Meeting Various Market Demands



-  3C~10C Fast Charge



-  Excellent Power, High Discharge Performance, Light Weight



-  Long Cycle Life, Discharge Capacity≥80% After 300 Cycles











1900mAh 2550mAh 1700mAh Lipo Rechargeable Battery 3.7 V 10C 15C Usb External Dog Toy Ball 782768SV2 1003055SV2 5      Application

1900mAh 2550mAh 1700mAh Lipo Rechargeable Battery 3.7 V 10C 15C Usb External Dog Toy Ball 782768SV2 1003055SV2 4

widely used in power tool, Camcorders, battery pack, electronic toy dog rechargeable battery, e-bike







1900mAh 2550mAh 1700mAh Lipo Rechargeable Battery 3.7 V 10C 15C Usb External Dog Toy Ball 782768SV2 1003055SV2 5      Packaging & Shipping

1900mAh 2550mAh 1700mAh Lipo Rechargeable Battery 3.7 V 10C 15C Usb External Dog Toy Ball 782768SV2 1003055SV2 4

Regular Safety Packing Or As Customer's Requirements.

Shipping By Sea, Air Or UPS, DHL, FedEx Express.



PAYMENT TERMS

1900mAh 2550mAh 1700mAh Lipo Rechargeable Battery 3.7 V 10C 15C Usb External Dog Toy Ball 782768SV2 1003055SV2 11



EXPRESS OPTIONS

1900mAh 2550mAh 1700mAh Lipo Rechargeable Battery 3.7 V 10C 15C Usb External Dog Toy Ball 782768SV2 1003055SV2 12









1900mAh 2550mAh 1700mAh Lipo Rechargeable Battery 3.7 V 10C 15C Usb External Dog Toy Ball 782768SV2 1003055SV2 5    Manufacturing Capability

1900mAh 2550mAh 1700mAh Lipo Rechargeable Battery 3.7 V 10C 15C Usb External Dog Toy Ball 782768SV2 1003055SV2 4

Capacity&Leadtime





● Stacking/per day:50Kpcs



● Winding/per day:2,00Kpcs



● Regular Model:≤8 weeks



● Customized:16-18 weeks(The first order, if nonew facility added )



1900mAh 2550mAh 1700mAh Lipo Rechargeable Battery 3.7 V 10C 15C Usb External Dog Toy Ball 782768SV2 1003055SV2 15 1900mAh 2550mAh 1700mAh Lipo Rechargeable Battery 3.7 V 10C 15C Usb External Dog Toy Ball 782768SV2 1003055SV2 16



The new plant will be located in the Dongjiang Bay Industrial Park, which will be a national high-end industrial park special for new energy, new information technology and intelligent equipment fields based on the “3+7” industrial park planning and deployment proposed by Huizhou relying on the Greater Bay Area, aiming to integrate Huizhou’s “1+4” industrial parks. The area of the new plant is estimated to be 30,000 square meters. With new high-end equipment and workshop environment, the goal is to build a high-end production line dedicated to high-end customers.





1900mAh 2550mAh 1700mAh Lipo Rechargeable Battery 3.7 V 10C 15C Usb External Dog Toy Ball 782768SV2 1003055SV2 5     Quality Management Syste

1900mAh 2550mAh 1700mAh Lipo Rechargeable Battery 3.7 V 10C 15C Usb External Dog Toy Ball 782768SV2 1003055SV2 4

Management Improvement according to international standards



1900mAh 2550mAh 1700mAh Lipo Rechargeable Battery 3.7 V 10C 15C Usb External Dog Toy Ball 782768SV2 1003055SV2 19 1900mAh 2550mAh 1700mAh Lipo Rechargeable Battery 3.7 V 10C 15C Usb External Dog Toy Ball 782768SV2 1003055SV2 20



Safety and environmental Certificates

capability&service

  • Simulation tests of safety certificates proceeded
  • Service of certificates application for customers

1900mAh 2550mAh 1700mAh Lipo Rechargeable Battery 3.7 V 10C 15C Usb External Dog Toy Ball 782768SV2 1003055SV2 21



Performance Test Capability



  • Electric Performance Test
  • Safety Performance Test
  • Mechanical Performance Test
  • Environmental Performance Test
  • Storing Performance Test







1900mAh 2550mAh 1700mAh Lipo Rechargeable Battery 3.7 V 10C 15C Usb External Dog Toy Ball 782768SV2 1003055SV2 5     FAQ

1900mAh 2550mAh 1700mAh Lipo Rechargeable Battery 3.7 V 10C 15C Usb External Dog Toy Ball 782768SV2 1003055SV2 4

Q1. What are the diferences betwee high C-rate and low C-rate lithium?

polymer (Li-Po) batteries.
In general, the diferences lie in the materials made of the positive & negative terminals, the area density design, the electrolyte ingredient, the septum data and the density of inside pieces.





Q2. How is a Li-Po battery made?

When a Li-Po battery is made, five main aspects should be considered carefully:

(1). Battery Pack should have suficient strength, so that the polymer battery inside could be efectively protected from mechanical shocks;

(2). The polymer cell should be fixedto the battery pack onits large surface area - no cell movement in the battery packshould be allowed;

(3). No sharp edge components should be inside the packcontaining the polymer battery, and meanwhile, suficient insulation layer between wiring and the cell should be used to maintain multiple safety protection;

(4). Ultrasonic welding is recommended for polymer tab connection to obtain low-resistance, high-reliability and light-weight properties;(5). Polymer packs shouldbe designed carefully so that no shear force is applied, and also, no heat is generated even when leakage ocurs for mishaps. PCM from electrolyte leakage should be isolated as perfectly as posible, and narrow distance between bare circuit patterns should be avoided.





Q3. What gases are generated in the formation process. Are they dangerous?

The generated gases include Co, CO2,H2, CH4 and so on. They are not dangerous because of low volume.





Q4. Why do we need formation process?

Organic solvents easily decompose on the negative electrodes during charging, leading to battery swelling, drop of cell capacity, and unsafety caused by activereaction. The purpose of the formation process is to form a solid layer called the solid electrolyte interphase (SEl), which is electrically insulating yet provides significant ionic conductivity. This interphase prevents further decomposition of the electrolyte after the second charging.





Q5. Why do Li-Po batteries bloat/swell?
The Li-Po batteries may bloat or swell due to the following reason:
1. Overcharging:Normally, the maximum charge voltage is 4.2V for RC batteries. If the batteries were overcharged beyond 4.4V, electrolytic oxidation process would happen, which generates mass gas leading to battery swelling.
2. Overheat:When discharging in high temperature or high C rate, the temperature of the inner part of the battery can be even higher, which gasify the electrolyte and results in swelling.
3. Shot-circuit.:If short circuit happened, the cell voltage would drop very fast and the electrolyte would be reactive to generate gases, leading to battery swelling.
4, Sealing:If sealed without proper processing, the battery cell would have water and air in, so that the electrolyte would be reactive to generate gases, leading to battery swelling.
